KIT 1,3 GHz 13 G2B KIT 1,3 GHz 13 G2B
KIT 1,3 GHz 13 G2B

Kit 1,3 GHz 13 G2B, Transverter

1296 ... 1298 MHz
199,00
Available from stock
incl. 19% Vat. plus shipping
net: 167,23 €
Qty.
    • Price from 2 Piece
    • 193,03 € per item
    • Price from 5 Piece
    • 185,07 € per item
RF range1296..1298 MHz
IF range144 ... 146 MHz
IF input powermax. 3 W
Output powermin. 0,4 W
RX gainmin. 20 dB
Noise figure @ 18 °Ctyp. 0.8 dB
PTT control+3 ... +14 V DC
Supply voltage+13.8 V DC (+12 ... 14 V DC)
Current consumptiontyp. 0.35 A (TX)
CaseTinplate
IF connectors / impedanceSMA-female, 50 Ohms
RF connectors / impedanceSMA-female, 50 ohms
  • Super low noise converter in the receive path
  • Transmit gain and receive gain separately adjustable
  • Internal stabilized oscialltor with precision crystal heater (40° C)
  • Control output for additional amplifier stages or a coaxial relay
  • PTT can be switched by voltage on the IF connector or by connecting the PTT pin to ground
  • Detector output (DC voltage) for monitoring the output power
  • Small mechanical dimensions due to the use of state-of-the-art SMD parts
To achieve a successful construction of this transverter the builder has to have experiences in the use and handling of SMD-parts. Further more experiences with smaller projects in microwave circuits arevaluable. The construction of this transverter KIT is NOT a beginners' project!
ESD sensitive devices (for example FETs) must be handled carefully.
